jv3 help please

[Aero Signs]

Can any one please Diagnose this problem by looking at this picture.
Jv3 was working fine and then it just Stated to print out of alignment

Offsite pics replaced. Please read our rules and instructions on photo posting.



[sthrillseeker2]

probably encoder strip

clean your encoder strip with damp cloth and light soap, rinse it clean with damp cloth be careful not to fog it or leave smudges behind

if not it can be motor or encoder eye

just went through this myself, mine was the eye



[Redz Signs Inc.]

+1 on the encoder strip. also i would just check you alignment anyway just because it alwayz a good thing to do. u can also use isopropyl alcohol on the strip as well.



[NEGD]

clean your encoder strip

+1 anytime i see something similar to this it's the strip.



[Aero Signs]

Thank you all very much.
You guys saved the day.
Also thanks to the creators of Signs101.
We are fortunate to have it available to us.




By any chance does any body out there have a
pdf of the jv3 service manual, I need to tackle the
alignment procedure.



[Redz Signs Inc.]

send me youe email adress ill send u a copy
