Mutoh Smart Chip Bypass

[Neotype]

Hi All, I have recently aquired a VJ-1626UH UV Printer, im now in the process of repairing the errors and i am at a point where to go further i need to have ink cartridges installed, does anyone know a way that i can get around this so i can test further?
I am just getting (12356) S/C Read Err, it came with 5 **ECO-SOL Cleaning cartridges with it and a CYAN Cartridge, which i installed on the 4th slot, I just dont want to spend 800$ just to get new cartridges then find out that its going to be a boat anchor. does anyone offer a service where they can update the printer to bypass the smart chip?

TA



[Ssignature]

You could change the charge flag in diagnostics to user/init: not charge and it would pump the cleaners through the system



[Neotype]

Ive tried that aswell, but being ECO-SOL Cleaners im getting S/C Ink Err as well, allthough i have one UV Cleaning cartridge and that seems to read fine wherever i put it.



[Ssignature]

The other reasonably priced solutions are (1) Have Mutoh generate a ULK file which will let you run for 2 weeks without cards (free) or (2) buy smart cards from STS, Triange, Bordeaux or other 3rd party ink companies



[Neotype]

Oh right, i will look into reaching out to mutoh tomorrow, but also looked into just getting the cards, and seems like digitalsigntech is the only one that does UV inks, hope i can get the ULK file first and figure out how to connect to the printer using MSA,
still having issues with the IP Settings not showing up in the menu as well (checked the menu options).
Thanks heaps Sir, very insightful info



[Ssignature]

Oh right, i will look into reaching out to mutoh tomorrow, but also looked into just getting the cards, and seems like digitalsigntech is the only one that does UV inks, hope i can get the ULK file first and figure out how to connect to the printer using MSA,
still having issues with the IP Settings not showing up in the menu as well (checked the menu options).
Thanks heaps Sir, very insightful info

The newer Versions of MSA require secure passwords. MSM will do it.
If any items don’t show up in the menu, someone has turned off the asterisks in the Menu Option item in the menus



[Neotype]

my menu options only goes up to 21 and none of them have the IP menus
20 All ON [ ]
21 All OFF [ ]

i notice on some of the research ive done, the IP options are around 24-25



[Ssignature]

Toggle the asterisk on in All on, then look in the Setup menu for IP Address
