black in spots and overspray

Discussion in 'Roland' started by Msrae, Jul 24, 2012.

  1. Msrae

    Msrae Rae

    209
    1
    18
    Mar 6, 2011
    Utah
    I have read up on a few posts about overspray.

    I have done 2 manual cleans, also took an led light and checked for lint. I did happen to find two stray teeny tiny pieces of fiber. I removed all that I could see and printed again. Still getting this bad black print. Does it still look like it could be lint? I am also getting what almost appears to be "drag" marks where the ink is dragging in lines across the vinyl.

    It was printing fine on this media with this profile about 2 weeks ago.

    Any ideas on what to try next? I know I also have some black drop out. The test print has looked like this since I purchased the machine.

    (ps - yes, I know the magenta is out on the second test print, it ran out on the last full clean I ran).


    Attached Files:

    Tags:
  2. Msrae

    Msrae Rae

    209
    1
    18
    Mar 6, 2011
    Utah
    Well, I brought my test print into my local supplier (Regional Supply) and they were pretty helpful. They suggest this is not lint but rather a print head issue. Figured I would post up the outcome for anyone else who might want to know.

    Their suggestion:

    Do a manual clean, take the swab and saturate it with cleaning fluid and dab/hold it on the print head (do not rub the head :p) bring it back to park mode and let it sit for a bit, then do a few powerful cleans.

    Going to try this and let you know the outcome. Hopefully my black printhead isn't just dying :(

  3. rjssigns

    rjssigns Major Contributor

    4,261
    200
    63
    Jun 4, 2007
    Home Office
    Whose ink are you using? I only ask because some inks don't have real swift quality control and oversize pigment particles can cause what you are experiencing. Ask me how I know.

  4. Msrae

    Msrae Rae

    209
    1
    18
    Mar 6, 2011
    Utah
    I have the Roland eco-sol inks (at least the black is). I have been slowly changing them out as I run out of inks. The new brand I have been switching to is Solaris Max-Live Genesis. However, both of my black cartridges are still the original Roland brand. Which brand did you have issues with?

  5. walters signs

    walters signs Member

    27
    0
    1
    May 8, 2008
    did the ink head swabbing work?

  6. Msrae

    Msrae Rae

    209
    1
    18
    Mar 6, 2011
    Utah
    In the long run, I got if fixed. The best fix was actually the suggestion of taking a bright led light and shining it on the heads. I found a teeny tiny thread there. I think that may have been the culprit. I did another head swab, and another cleaning. The print looks great now.

  7. DRamm76

    DRamm76 Member

    496
    1
    0
    May 17, 2007
    So you're not actually flushing the machine properly when switching to the 3rd party inks but rather just pulling the empty cartridge out and replacing it with something else and mixing? That's worse than using 3rd party alone.

    Are the heads capped properly? I would do medium cleanings over a powerful any time. You're going to be wasting a ton of ink with powerful cleanings. But then again, since 3rd party ink is so much cheaper it won't matter right?

  8. Msrae

    Msrae Rae

    209
    1
    18
    Mar 6, 2011
    Utah
    Actually, I am going back to OEM inks. I did a little research and decided this was a better way to go for me.

    Yes, the heads are capped properly. The print now looks just fine. Thanks for your help.

    My supplier never said a thing to me about not mixing inks, so I was unaware that this would be a problem. Thanks for the heads up. I will keep that in mind if I ever decide to go 3rd party ink again.
