    Hello.
    What tools and hardware do you use when wiring channel letters?
    How do you connect, say, a dozen of wires? Do you use wire nuts? Do you crimp wires and use terminal blocks?


    Attached Files:

    Tags:
  2. equippaint

    equippaint Very Active Member

    1,556
    450
    83
    Oct 10, 2014
    Florida

    • Hilarious! Hilarious! x 4
    • Like Like x 2
    • OMG / Wow! OMG / Wow! x 1
  3. henryz

    henryz Member

    367
    83
    28
    Nov 6, 2012
    Long Beach, CA
    We use wire nuts, you could use other connector if you want.

    • Agree Agree x 1
  4. bannertime

    bannertime "You guys do banners, right?"

    1,404
    337
    83
    Sep 8, 2016
    Arlington, TX
    I used to use these when I did electrical work on oil rig/drilling equipment. These things are amazing and stood up to a lot of abuse. UL listed. Assuming they are allowed in signage.

    https://www.wago.com/221/us/

    • Like Like x 1
  5. equippaint

    equippaint Very Active Member

    1,556
    450
    83
    Oct 10, 2014
    Florida
    That's the problem with this post. It's a bit of a silly and scary question considering that he should already know codes and be versed on how this stuff is done. If you have to ask, you shouldn't be doing it.

    • Agree Agree x 2
  6. Texas_Signmaker

    Texas_Signmaker Very Active Signmaker

    2,568
    968
    113
    Oct 21, 2016
    Frisco, TX
    I'm assuming your talking about 12v DC?

    12 is too much... I've seen people do 10 or 12 on one large wire nut and it looks like a sloppy mess. Split it up and make it manageable... I don't like having more then 6.


    And on a side note... why are people wrapping lamp sockets with masking tape??

    Last edited: Jun 10, 2019
  7. equippaint

    equippaint Very Active Member

    1,556
    450
    83
    Oct 10, 2014
    Florida
    If it's 12v use that terminal block with jumpers or a stud. Terminal blocks really just make diagnosing problems easier. You cant load up 12 wires on a wire nut, even 12v will get hot and start a fire. I'm not real crazy about wire nuts with stranded either but this is out of my AOR. Those stab in connectors banner posted work well if youre doing production work

  8. visual800

    visual800 Very Active Member

    3,670
    197
    63
    Aug 4, 2010
    montgomery, alabama
    crimp nuts on our repairs

  9. JBurton

    JBurton Signtologist

    367
    67
    28
    Sep 28, 2017
    Arkansas
    If using the regular jacketed wire, get some 12 ga non jacketed and some scotchloks, run the 12 ga behind the wall the length of the sign, tap into it with scotchloks behind each letter, throw the wire nuts at unsuspecting individuals from your bucket truck.
    If you're asking how to put 12 wires in a single connector, you're not qualified to do this part of the job and need an electrician to show you the ropes. southwire-speaker-wires-56911845-64_1000[1].jpg 6108tvgCsgL._SL1200_[1].jpg

    • Agree Agree x 1
  10. Devon19515

    Devon19515 Member

    82
    14
    8
    Jan 12, 2015
    Georgia

    The masking tape on the lamp sockets keeps the bulb from bouncing loose in transport.

  11. nolanola

    nolanola Member

    233
    7
    18
    Sep 24, 2014
    New Orleans
    Thank you for your input.
