Fluo yellow
- Thread starter 31legen
- Start date
I'm just amazed how many people are asking absolute noob questions like how to print pearl color and fluor yellow and gold and stuff I mean just look at the CMYK color gamut if you find your color there you can start trying out different combinations but 'gimme the rgb value for... ' is not like a serial number for your newest hacked game. First of all RGB is a combination for LIGHT and CMYK is for material. My best advice is to take a color theory class.
Solventinkjet
DIY Printer Fixing Guide
I agree with the above post. There just isn't any way you will get even close. Florescent yellow is requires either a light source or special pigments that just aren't in the inks these printers use. You can get a very yellow yellow but it won't ever come close to florescent.
When my customers ask for fluorescent yellow, what they are really wanting is a yellow that is slightly tinged with green. You need to explain to them that you cannot print an actual fluorescent color with regular CMYK inks, and there are no digital printers which carry actual fluorescent inks. Unfortunately there are some vendors out there who aggressively advertise they have fluorescent graphics, and so the customers believe that they do. This is a description of the color commonly called fluorescent yellow, or electric lime: Fluorescent yellow / [HASHTAG]#ccff00[/HASHTAG] hex color ([HASHTAG]#cf0[/HASHTAG])
I find that to print it, I cannot use 20C 0M 100Y 0K as they describe, but have to use less cyan and pull back a bit on the yellow too.
I find that to print it, I cannot use 20C 0M 100Y 0K as they describe, but have to use less cyan and pull back a bit on the yellow too.
"Nearly possible" is still impossible. if you need fluro, no print is good enough. Cut some vinyl or get some paint dude!
jfiscus
Rap Master
He has a machine with more than CMYK inks for those here just quoting "CMYK spectrum" so he can hit a lot of colors outside of the standard 4-color spectrum. In your RIP turn up your saturation to 25% more in all colors and print another Pantone chart out and then turn them all up 50% and print another chart. We have a couple charts for those customers who want to hit a very specific color that isn't possible with most eco-solvent inks without saturation/ink density increases. Makes it a bit finicky sometimes, but it might make a light greenish-yellow a lot closer to a a fluorescent color.
Be careful running a lot of outdoor prints with those additional colors on in your RIP, those colors are NOT warranted for any length of time by Epson and do fade. We recently went with a 60600 (dual cmyk) to alleviate issues we had with our previous 70670/70675 series printers.
Be careful running a lot of outdoor prints with those additional colors on in your RIP, those colors are NOT warranted for any length of time by Epson and do fade. We recently went with a 60600 (dual cmyk) to alleviate issues we had with our previous 70670/70675 series printers.
swordguy3222
New Member
What rip are you using for printing?
bob
It's better to have two hands than one glove.
DayGlo [trademark] and generic fluro, for want of a better term, colors are made with pigments ground to a specific wavelength. They essentially are monochromatic and are not reproducible in CMYK, RGB, LAB, or any other color space. They very much are their own thing color wise.
Last edited:
I'm using Onyx gamaprint
swordguy3222
New Member
Terrible rip. Invest in a better rip, it'll make hitting more colors a lot easier. I use colorgate, and it's so nice. I run 4 printers off of it.
ColorCrest
All around shop helper.
Profiles are very specific to printer / ink / media and their settings, you know? You never mentioned what media you’re using or a plethora of other settings. If someone were to send you a profile, how would you know if your machine behaves the same as the one from which the profile was created?
In any case, it was easy for me to lookup fluorescent yellow at the Pantone website. Using the sRGB color space the values are: 237, 255, 0, or edff00 in Hex, or 96, -23, 92 in Lab for PANTONE 13-0630 TN Safety Yellow.
Sure enough, holding a fluorescent yellow hi-lighter marker and a fluorescent shop-cloth against my monitor confirmed the match.
Despite what you may have read in earlier posts, the color seems to fit in sRGB and certainly Lab. After all, the Lab color space describes mathematically all perceivable colors and even the lowly sRGB color space standard for computer monitors can emit as much yellow-green light as the fluorescent yellow you’re looking for. Although many ICC profiles reach the gamut, the prints from your machine will only come close (as you expect) because the ink and media simply does not have the characteristics of other true fluorescent processes such as dye sublimation printing or special ink with optical brightener additives.
You might check any profiles you have by using the gamut warning tool in Photoshop using the values from above. I find it’s within gamut of many profiles I have on my system for media I use.
Good luck.
ColorCrest
All around shop helper.
sRGB, as described and the document color mode is RGB of course.
