Gradients printing streaky

[madone]

This is same file, media and climate controlled shop, only difference is TR2 conversion, can anyone help?

BTW, the logo and text prints fine over the gradient?

Thanks



[SignMeUpGraphics]

What does a nozzle test look like?



[Boudica]

Without more to go on... Clean the heads... Or perhaps a bad roll of vinyl?



[madone]

Sorry, I left out nozzle test is fine , tried different media. The only thing is the gradient, the logo and text prints fine on top of it?



[Boudica]

So, trouble shooting mode... Are you enlarging the file in the rip? And what file type are you pulling in?



[SignMeUpGraphics]

Are you only getting this on orange gradients?
What about something like blue?

Good question about enlarging above too... if you're doing a big enlargement this could be contributing.



[mcclaysign]

Hmm, the only thing I can think of is to clean the decoder strip with alcohol.



[Zoogee World]

It could also be the profile you are using. I've found on my SG-300, that since I changed to the TR2 inks, the profiles aren't as good and I've had to play and adjust to work with most medias, so I even need to do 2 prints opposed to only having to do one on the TR inks, because the TR2 inks aren't printing as dark.



[madone]

I had my buddy print a piece on Mimaki and it did fine, must be setting issue??



[Zoogee World]

I had my buddy print a piece on Mimaki and it did fine, must be setting issue??

You'll need to play around with the profiles, heat setting and print speeds. I find personally the print quality isn't as nice on the TR2 inks, due to all the profiles not being very good.



[balstestrat]

Did you already try the damper fill command?
Doesn't necessarily help but I guess worth a try...
