Need Help mutoh value jet 1624 print issue

kamenbraykov

New Member
Hi guys

I'm having a print issue with our VJ1624 - perfect nozzle check but it has shadow print on the black colour only
I thought it may be from the encoders so change them both but no luck at all :(
VJ-1624 PF ENC Scale
VJ-1624 encoder strip

Head alignment looks good

Any ideas?

Thanks
Kamen


Attachments

  • 20180425_145756.jpg
    1 MB · Views: 439

Solventinkjet

DIY Printer Fixing Guide
Are you sure the head alignment looks good? That looks like classic bad bi-directional alignment.

Edit: Actually on a close look it looks like you may have some electrical issue going on. I would check your head cables and make sure they are clean and not damaged. That's a good place to start. Unfortunately, it could be the head failing as well.


kamenbraykov

New Member
Are you sure the head alignment looks good? That looks like classic bad bi-directional alignment.

Edit: Actually on a close look it looks like you may have some electrical issue going on. I would check your head cables and make sure they are clean and not damaged. That's a good place to start. Unfortunately, it could be the head failing as well.
Will check the cables now - I've got spare set :)

An engineer did some alignment and it is now printing like this
Is it possible to do this bi-di alignment by my self

Thanks in advance :)


Solventinkjet

DIY Printer Fixing Guide
There are a lot of bi-directional alignments you can do but the one that will tell you the most is the one in the user menu. Go to Menu>Setup>User Type>Adjust Print. You can print the rough pattern and adjust it and then print the fine pattern and adjust that. Then run a print and see how it goes.


kamenbraykov

New Member
There are a lot of bi-directional alignments you can do but the one that will tell you the most is the one in the user menu. Go to Menu>Setup>User Type>Adjust Print. You can print the rough pattern and adjust it and then print the fine pattern and adjust that. Then run a print and see how it goes.
We did this print adj to all patterns it looks fine to me a bit better but still doubles vertical lines - vertical issue only


Attachments

  • 20180425_173942.jpg
    1.1 MB · Views: 372

kamenbraykov

New Member
this is what I've got so far - hopefully is not the head

all those photos with mag. glass


Attachments

  • 20180425_180703.jpg
    949.1 KB · Views: 354
  • 20180425_180719.jpg
    877.8 KB · Views: 292
  • 20180425_180730.jpg
    867.4 KB · Views: 324
  • 20180425_180808.jpg
    1.1 MB · Views: 380
