Need a little help-FLEXI 8.0v1

Discussion in 'Flexi' started by EnergyDesign, Sep 23, 2008.

  1. EnergyDesign

    EnergyDesign Active Member

    538
    0
    0
    Apr 19, 2007
    I need to print and then contour cut 1,000 numbered rectangles. Numbers 0000 - 1000. I know flexi has a automated process to do this, but I cannot figure it out. I definitely do not want to type each number into it's own rectangle. Any help available? is there a tutorial somewhere i can read on it, besides whats in the manual? the flexi manual like most of it's functions are CRAP! At least to a fairly competent, graphic designer...:thankyou:

    Tags:
  2. EnergyDesign

    EnergyDesign Active Member

    538
    0
    0
    Apr 19, 2007
    example here


    Attached Files:

  3. high impact

    high impact Very Active Member

    Go to auto serialize under the arrange drop down.

    I'm not at the shop - trying to remember, this should be close...

    Type out your first number in choice of font and size, select text (numbers), go to arrange, click auto serialize, set your number of columns, click ok, click serialize. Keep us updated.

  4. EnergyDesign

    EnergyDesign Active Member

    538
    0
    0
    Apr 19, 2007
    but would i have to layout 1,000 rectangles first

  5. DRPSignsNGrafix

    DRPSignsNGrafix Very Active Member

    1,449
    0
    0
    Nov 3, 2005
    no just layout the first one. Then click on the number and tell it to auto serialize

  6. Arstron

    Arstron Member

    134
    0
    0
    Oct 11, 2006
    I just tried it, just like DRPSigns said, layout the first one exactly how you want it, select it and then auto serialize and it will put the box and what ever else is sellected with the numbers.

  7. Mike Paul

    Mike Paul Major Contributor

    5,438
    8
    38
    Dec 30, 2003
    NJ
    Make sure your paragraph style is set to align center.

  8. high impact

    high impact Very Active Member

    Rick, did you get this?
