Need Vector Help Quick!

Discussion in 'Clipart, Vehicle Templates and Digital Files' started by CMRGRAFIX, Feb 28, 2007.

  1. CMRGRAFIX

    CMRGRAFIX Member

    39
    0
    0
    Apr 30, 2006
    I am struggling with the concept of how to vectorize a .jpg image. I have flexi 7.6 adobe illustrator cs, adobe photoshop, corel draw 3x. ANy help would be appreciated greatly I have to have the job done no later than friday. OR I would be more than willing to pay someone to vectorize them for me.??
    My email is cgm12785@charter.net I have the file but dont know how to post it


    Attached Files:

    Tags:
  2. mladams7259

    mladams7259 Very Active Member

    1,319
    0
    0
    Sep 7, 2006
  3. Ken

    Ken Major Contributor

    5,484
    2
    38
    Feb 7, 2005
    BC
    In Corel X3, try the Power Trace or just the Trace function.
    I recommend the Vector Doctor also.
    Ken

  4. Bigdawg

    Bigdawg Just Me

    7,458
    133
    63
    Jun 8, 2005
    Sunny Florida
    This is easy and a good one to learn on. The font is Garamond. Place the image in Illustrator CS. Use control 2 to lock it down. Now use the pen tool to click each place that there is a corner. Make sure you use no fill and only a stroke. You'll probably see real sharp spikes instead of the flat top like the example, so under the stroke palette there is a miter limit. It is probably on 4 - change it to 1 and you should be able to get the look you want. After you have set the type and drawn the line. Control-shift-O to change the fonts to outlines. Then select the line you drew and go to the Object menu to paths to outline stroke. You should be able to import into Flexi now so you can cut it.

    Good luck!

  5. NukeProof

    NukeProof Member

    100
    0
    0
    Aug 31, 2006
    open X3. go to the bitmaps tab, trace bitmaps, line art. you can trace it in 20 seconds. if any of the lower letttering give you problems, re-type them out using Garmond Bold as bigdawg stated

  6. Shovelhead

    Shovelhead Major Contributor

    10,882
    15
    0
    Dec 5, 2003
    OR if you want to learn....

    how to do it yourself.....
    go to wire mode and use your pen tool and place the fonts.


    Attached Files:

    • 222.jpg
      File size:
      34.2 KB
      Views:
      61
  7. stuart@accupress.com

    stuart@accupress.com Member

    170
    0
    0
    Nov 10, 2005
    Vector Doctor...

  8. Replicator

    Replicator Major Contributor

    10,230
    9
    38
    Nov 19, 2006
    Sun City, AZ
    Corel X3 - 45 seconds !


    Attached Files:

  9. canadianchef

    canadianchef Member

    110
    0
    16
    Jan 15, 2006
  10. CMRGRAFIX

    CMRGRAFIX Member

    39
    0
    0
    Apr 30, 2006
    Thanks guys for all the help I ended up using vectordoctor cause I was so crunched for time. I have since went back and learned all the methods you offered up as help. Thanks again...

  11. ChicagoGraphics

    ChicagoGraphics Major Contributor

    4,770
    53
    48
    Feb 27, 2007
    World
    Recreate it in 15 minutes your done in Flexi

  12. ChicagoGraphics

    ChicagoGraphics Major Contributor

    4,770
    53
    48
    Feb 27, 2007
    World
    Import it into Flexi then goto bitmap on the tabs on top then goto vectorize then to bezier, dones in seconds then just change your colour to black & red
