no color from one printer head roland sp 540v

Discussion in 'Roland' started by Johanswe, Dec 1, 2020.

  1. Johanswe

    Johanswe Member

    28
    0
    1
    Oct 24, 2020
    Sweden
    I have changed both cap top, wipers, pump, both printer heads. I only get black and blue, not yellow or red. what's wrong? can someone even answer how often I should clean my heads? (Manual and the programs in the machine)

  2. Johanswe

    Johanswe Member

    28
    0
    1
    Oct 24, 2020
    Sweden
    Dampers are changed and I have color in them

  3. Solventinkjet

    Solventinkjet DIY Printer Fixing Guide

    4,310
    812
    113
    Aug 2, 2011
    Denver, CO
    If you know ink flowing through the head and it still doesn't fire, the head fuse has blown on the main board. Depending on how old your model is, it might be a socketed fuse which is easy to change but if it's older, you'll have to solder it.

    • Like Like x 1
    • Agree Agree x 1
  4. Johanswe

    Johanswe Member

    28
    0
    1
    Oct 24, 2020
    Sweden
    the color (yellow and red) goes past the cap top and through the pump.

    where is the main board? what does the fuse look like?

  5. Jim Hancock

    Jim Hancock Active Member

    556
    100
    43
    Nov 11, 2008
    Delray Beach, Florida
    Power down and unplug the power cord. Remove the back cover over the electronics. See the attached drawing for fuse location. The 2 fuses will be between the 2 large white ribbons that go into the carriage train. Set your multimeter to the most sensitive resistance scale. Use a regular multimeter, not a clamp-on voltmeter. Good fuses will read zero. A bad fuse will not read anything.


    Attached Files:

    • Agree Agree x 2
    • Like Like x 1
  6. Bryce I

    Bryce I I'm Brie

    34
    1
    8
    Jul 18, 2019
    Northern Ca.
    Looks like Jim has the answer to your issue, but as far as your general question:
    I do a manual head cleaning once a week.
    At the beginning of every day of printing, I do a test print to check the heads. If There's any dots missing, I'll have the machine do a regular cleaning.

    • Like Like x 1
  7. Jim Hancock

    Jim Hancock Active Member

    556
    100
    43
    Nov 11, 2008
    Delray Beach, Florida
    This should be how every printer operator should start the day...

    • Like Like x 1
  8. MikePatterson

    MikePatterson Head bathroom cleaner.

    I agree. We start out every day with a test print and color bar print. Then after lunch we do the same. But our printers are running pretty much non stop all day long and I have 1 woman that babysits 3 machines and 2 plotters.

    As for your problem its either a fuse or ribbon cable.

    • Like Like x 1
  9. Johanswe

    Johanswe Member

    28
    0
    1
    Oct 24, 2020
    Sweden
    thanks for all the answers! Has now got the mainboard back and now it should work. BUT still no red and yellow color, what can I check now?

  10. Solventinkjet

    Solventinkjet DIY Printer Fixing Guide

    4,310
    812
    113
    Aug 2, 2011
    Denver, CO
    If you didn't fix the issue that made the fuse pop in the first place, it might have popped again. Make sure you are working with themachine turned off and unplugged. Then wait for about 15 minutes before working on it. Then check the head cables on both ends for damage, ink splatter, or corrosion. Replace as necessary. It's usually the head cables but I like to air dust all the terminals just in case. At the end of the day, if the fuse isn't blown and it still won't fire, the head is either clogged completely or fried electronically.

    • Agree Agree x 1
  11. Johanswe

    Johanswe Member

    28
    0
    1
    Oct 24, 2020
    Sweden
    the guy who helped me is working on building similar cards and has replaced the components that burned the fuse.

    I'll have to check the cables tomorrow. can I check something on my head to see if it is burned?

  12. Jim Hancock

    Jim Hancock Active Member

    556
    100
    43
    Nov 11, 2008
    Delray Beach, Florida
    Which components that burned the fuse? Please be specific...

  13. Johanswe

    Johanswe Member

    28
    0
    1
    Oct 24, 2020
    Sweden

    I do not know what they are called or look like, sorry.

  14. Johanswe

    Johanswe Member

    28
    0
    1
    Oct 24, 2020
    Sweden
    I only know that four components were broken.

  15. Johanswe

    Johanswe Member

    28
    0
    1
    Oct 24, 2020
    Sweden
    today I have changed the cables from printerhead which worked (blue and black) to the other, and then it prints yellow and red. the cables are checked with a multimeter and are intact. can I check something else?

  16. Johanswe

    Johanswe Member

    28
    0
    1
    Oct 24, 2020
    Sweden
    there were two c4131 transistors that were burned and they have been replaced and now it works. Thanks for all the answers!
