Options for getting large patterns digitized?

Discussion in 'General Signmaking Topics' started by JoeRees, Nov 1, 2019.

  1. JoeRees

    JoeRees Member

    32
    11
    8
    Apr 7, 2015
    New England
    I need a way to vectorize large paper tracings in a 1:1 scale so that when I plot them out they match the original hand-tracing very closely. I'm talking about originals that are up to 3' x 4'. I'm thinking that a large digitizer tablet or oversized flatbed scanner would be a good tool for the job but who has these anymore? I can attest that trying to draw over a photo of the original with CorelDRAW's freehand tool is not practical because of inherent distortions in a cellphone pic - no matter how perfectly you follow the pic the resulting vector paths never really matches the original tracing, resulting in a seemingly endless spiral of editing and re-plotting to check improvements...I eventually get there but holy-moley what a clunky and wasteful process. Wasteful because I don't have a pen-drawing plotter and must cut vinyl for each test plot. There's got to be a better way. How would you handle a task like this or do you know of a service who can scan my patterns full scale?
    Thanks,
    -Joe-

    [​IMG]

  2. Andy D

    Andy D Very Active Member

    1,923
    285
    83
    Oct 20, 2014
    Hattiesburg, MS
    Most print shop that provides "blue print" services has large scanners. Our scanner kind of looks like a plotter, you load the print on one side
    and it runs it through, so it can be 3' x whatever length.

    • Agree Agree x 2
    • Like Like x 1
  3. 2B

    2B Very Active Member

    2,955
    359
    83
    May 5, 2011
    TX
    try contacting a CAD printer, they regularly convert construction drawings to digital

    • Agree Agree x 1
  4. Gene@mpls

    Gene@mpls Very Active Member

    1,986
    82
    48
    Jun 17, 2003
    Blaine, Mn
    The key is taking the picture square to the drawing and moving farther away from it, as long as you can zoom in before you trace it. And then plot it on paper instead of cutting it.

    • Agree Agree x 2
  5. sardocs

    sardocs Active Member

    567
    97
    28
    Jun 17, 2005
    pender harbour bc
    Is there no way to fit a pen to your plotter? Our plotter wasn't designed for pens but we regularly fit a ballpoint or a sharpie on the carriage for exactly this purpose.

  6. Andy D

    Andy D Very Active Member

    1,923
    285
    83
    Oct 20, 2014
    Hattiesburg, MS
    Advice I have gotten from this site from other members about taking images with little to no distortion is to:
    make sure you are square and level with the subject, back up to where the details you need are still visible, don't zoom in, set your camera to the highest dpi/ppi,
    make sure the lines are what the camera is focusing on & take the pic.

  7. James Burke

    James Burke Being a grandpa is more fun than working

    3,186
    302
    83
    Jan 2, 2010
    Mitten State
    Tape it to the wall, set your camera on a tripod, snap a photo, trace off the photo.

    The arcs in your drawings could be traced very easily with AutoCAD.

    With AutoCAD's "start, end, direction" arc function, you simply click on an arc's start point and end point, and then drag the curve so it matches your pattern. Easy peasy...and really fast.

    JB

  8. JBurton

    JBurton Signtologist

    1,164
    231
    63
    Sep 28, 2017
    Arkansas
    I've gone as far as to tape the print to the wall, then tape the phone to a stand so I know my phone is (mostly) perfectly in plain with the pattern.
    Also find a way to MacGyver a pen in that plotter. On my old graphtec, I'd wrap masking tape around a pen or sharpie until it's about the same diameter as the plotter blade. Then just give the thumb screw a couple of extra turns to hold it still. Sharpie is easier to get going, as you don't tend to punch holes in the paper if you set the pen to close to the paper.

  9. shoresigns

    shoresigns Very Active Member

    1,463
    264
    83
    Nov 1, 2011
    Vancouver, BC
    If that's the case, ignore all the advice you're getting about cameras and find someone with a large scanner. Unless someone here knows how to perfectly compensate for all the different types of distortion that a camera introduces.

    • Agree Agree x 2
  10. Jester1167

    Jester1167 Very Active Member

    I see you used the words "very closely match" and I see that the original is black and white. Unless it's on a curve I would have taken a picture, traced it, scaled it, pen plotted it, make any minor adjustments, and then cut it. That would be very close in a lot less time then the hand tracing and then finding someone to scan it $, and you still have to vectorize it.

    Even if it is on a curve, taking a picture of what you have now will be cheaper and faster and match "very closely.

    Lens distortion is almost nonexistent even on your cell phone if you keep the image in the center 1/3 of pic and you shoot straight on. Don't use the wide-angle lens if you have one.

    Below shows the lens distortion on my Galaxy S10+. 8.5 x 11" with a .5" grid and none of the images were cropped.
    Order of images Zoom, Normal, Wide Angle
    1 Zoom Lens.jpg 2 Normal Lens.jpg 3 Wide Angle Lens.jpg

  11. woolly

    woolly Active Member

    623
    16
    18
    Sep 24, 2007
    Cornwall uk
    been trying to justify a roll scanner but still use a camera if really critical normally draw a known size box around the drawing to help trap any errors.
    one tip i would draw one vector through the centre of the lines then add a pen width to suit. then convert pen width to outline so end up with parallel vectors.
    if a pen a dot shape is used it will give you the rounded ends

  12. McDonald Signs

    McDonald Signs McDonald Signs & Graphics

    44
    3
    8
    Feb 11, 2013
    Guin, Alabama
    I have a tile floor in my shop made up of square tiles and grout lines. I lay the paper pattern on the floor and get right above the pattern on a small step ladder, square up the lens in my Iphone with the grout lines in the
    tile floor in all sides of the lens and snap a photo. Then email the photo to my computer, import to my drawing program and size the pattern full size in my program and trace it on screen.
    Works pretty well for me, we do alot of vehicle decals this way.....

  13. Bobby H

    Bobby H Very Active Member

    1,966
    120
    63
    Feb 4, 2005
    Lawton, OK
    That approach can only, at best, get in the ballpark in terms of accuracy.

    First of all, mobile phone cameras only stink when it comes to tasks like zoom. Mobile phones have fake zoom, not an actual optical-based zoom lens. They crop into the image and then blow up the cropped result. Lousy.

    A real camera with a real zoom lens, mounted to a tripod, will do far better. But even the results there get only so good. Perspective is always a distorting issue, no matter how far back someone positions the camera and zooms into the image. There's always some form of barrel distortion.

    Here's an idea. The approach won't be fun. But if executed properly the scanned results will be dead-on accurate. Take that pattern, or a traced copy it, and break it up into tiles small enough to fit in your scanner. Carefully draw a grid of squares across the whole thing, as well as some diagonal lines for extra aid in registration. Then cut all the squares apart and scan each square tile. You should be able to piece together the images in Photoshop or any other decent pixel-based image editor. The end result won't have any of the barrel distortion perspective fall-out that is always present in photographs. Every tile will be 1:1 accurate. You just have to fine-tune how all the tiles join together. It's a painstaking process just getting every tile oriented consistently in the scanner to minimize fine-tuning and editing on the back end.

    This approach isn't much different than the old scale grid approach used by mural painters.

  14. Greg Kelm

    Greg Kelm Member

    67
    8
    8
    Aug 20, 2019
    Rancho Cucamonga
    Best DIY I’ve found is to cut it up into manageable pieces, scan and stitch the files back together in photoshop/illustrator.

  15. Gino

    Gino Premium Subscriber

    32,495
    2,072
    113
    Jun 7, 2006
    PA
    I have no idea if this was said already, but if you don't have access to the correct tools or the original template....

    • Take a picture with no zoom at a distance where you get the whole thing in your field of vision
    • Next if you don't have a pen plotter, then print it out at about 25% of the original size
    • Put it under a light table and trace onto some paper
    • It looks like a buncha french curves and whatnot, so use those tools (which any sign shop has on hand) and recreat it at a reduced size
    • Now, scan it in at this reduced size and blow it up to whatever size you need
    I've done this many times and at a much larger size, than 3' × 4'

  16. JoeRees

    JoeRees Member

    32
    11
    8
    Apr 7, 2015
    New England
    Wow, great responses to my inquiry - thank you all so much for the advice.
    FYI, my first attempt at this was to divide the tracing into thirds, photograph them individually and stitch back together before attempting my initial vectorization - this proved useless as apparently all my thirds had significant distortion from being taken at too-close a range. My next attempt was to place my original drawing on the floor and get as far away as I could with the camera, standing on a chair so I could capture a single shot from about 6' away. One came out pretty close using this method but the other was still way off - damn distortion again. I could probably keep stabbing at it and figure out a way to pin to a wall as some suggested, with the camera on a tripod, etc...but my favorite advice from this post is to find a blueprint service that can scan an oversized original and just give me back a distortion-free bitmap to vectorize. I already did a Google search and turned up a few in my vicinity - one of whom I've already emailed asking if they had this capacity. I'll keep you posted on how that works out. THANK YOU THANK YOU!!

  17. JoeRees

    JoeRees Member

    32
    11
    8
    Apr 7, 2015
    New England
    Ok, I found a Minuteman Press 10 miles away from my door that can scan my originals and email me the resulting full-size bitmaps ( or copy them to my portable thumb drive) for $6per page - WHILE I WAIT!!! I'll be going there tomorrow and let you know how it works out. I am so glad I asked smart people, pats on the back for everyone.

  18. JBurton

    JBurton Signtologist

    1,164
    231
    63
    Sep 28, 2017
    Arkansas
    Everybody loves a happy ending! Glad to see this worked out.

    On a side note, has anybody ever had the thought of mounting a camera to their CNC and essentially convert it into a scanner? I'll be back...

  19. 54warrior

    54warrior Member

    443
    16
    18
    Apr 10, 2008
    Pennsylvania
    Most Staples now have the ability to scan documents that are 3 feet wide . I do this all the time when making templates for Side By Side buggies/UTV's and Four Wheelers.

  20. signman315

    signman315 Signmaker

    297
    93
    28
    Oct 5, 2015
    Edmeston, NY
    I've used an 11"x 17" cheap $100 scanner and scanned it in multiple pieces and rebuilt it in photoshop. I've mostly done this for fine art reproductions, and the customer's standards were really high, and it worked out great. Time consuming, but no wasted materials or special equipment required. Just be sure to give yourself plenty of overlap for each scan, and also buy a scanner that has the glass flush with the edges. Otherwise you are wrinkling the paper to mush it into the scanner, causing distortions at the edge of the scan and also potentially damaging the original. Best of luck!
